Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp

Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp
Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp

Large Image :  Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp

Product Details:
Place of Origin: Guangdong, China
Brand Name: YUYANG
Certification: ISO 9001:2015, RoHS, REACH,CE
Model Number: H9-908
Payment & Shipping Terms:
Minimum Order Quantity: 100 Pieces
Price: USD 0.60 - 4.00 / Piece
Packaging Details: Export-grade corrugated carton, 100pcs/carton
Delivery Time: 3-5 working days for stock, 15-25 days for production
Payment Terms: T/T,L/C,PayPal,Western Union
Supply Ability: 100000 Pieces per Month
Contact Now Chat Now

Stainless Steel Looping Gripper Hardware Global Lighting Components Self-Locking Cable Looping Gripper 2.5-3.5mm 150kg / 330lbs Satin Nickel High Security Wire Rope Clamp

Description
Compatible Cable Diameter: 2.5-3.5mm Max Load Capacity: 150kg / 330lbs
Safety Factor: 3× Rated Load (Tested) Body Material: Zinc Alloy
Surface Finish: Nickel Body Dimensions: 32×20×14mm
Unit Weight: 30g Locking Mechanism: Load-Activated Ball-Bearing Wedge Assembly
Cable Entry: Bi-Directional (Dual Channel) Operating Temperature: -20°C To +80°C
Highlight:

150kg Cable Looping Gripper

,

Self-Locking Cable Looping Gripper

Self-Locking Cable Gripper

Heavier Load = Stronger Grip — Engineered for Zero-Slip Safety

Cable Range
2.5-3.5mm
Max Load
150kg / 330lbs
Material
Zinc Alloy
Finish
Nickel
🛡️ CORE SAFETY FEATURE
Proportional Self-Locking — Load-Activated Wedge Mechanism

The gripper employs a precision ball-bearing and wedge geometry that converts suspended load into locking force. As the hanging weight increases, internal wedge elements are driven deeper into the cable contact interface, generating proportionally higher clamping force. This physics-based self-energizing lock eliminates the single point of failure found in spring-loaded or friction-pad grippers — there is no spring to fatigue, no adjustment screw to vibrate loose, and no clamping pad to wear thin over time.

  • Load-proportional locking: no external energy or tensioning required
  • Precision ball-bearing wedge assembly with surface-hardened contact faces
  • Zero spring fatigue — indefinite service life under rated load
  • Vibration-proof: wedge maintains grip even under mechanical oscillation
🛡️
Fail-Safe Design
3* Safety Factor
Tested to 3* Rated Load
🔧
Tool-Free Operation
Fingertip Control
Quick One-Hand Adjustment Without Tools

Despite its heavy-duty safety rating, the gripper remains effortless to operate. Press the ergonomic release button with one finger, glide the cable to your target position, and release — the wedge re-engages instantly. This tool-free design eliminates the need for Allen keys, screwdrivers, or crimping tools at height, significantly reducing installer fatigue and on-site labor hours on large commercial projects.

  • One-finger release — fast position adjustment at height
  • No set screws to strip or lose during installation
  • Compatible with standard 7*7 and 7*19 stainless steel wire rope
  • Ergonomic button design for gloved-hand operation
Bi-Directional Looping for Versatile Rigging

Dual cable channels allow wire rope to enter from either side, enabling loop formation around beams, trusses, and ceiling grids of any diameter. The gripper is purpose-built for suspension systems where safety redundancy is critical — each gripper forms an independent, self-reinforcing loop that cannot loosen under load, providing peace of mind in public-access areas like retail atriums, theater lighting grids, and museum exhibition halls.

  • Bi-directional entry for closed-loop rigging configurations
  • Each loop is independently self-locking for safety redundancy
  • Ideal for public-access overhead installations
  • Pairs with Ø1.0mm-5.0mm 7*7 or 7*19 stainless steel cable
🔁
Dual Channel
Closed-Loop Secure
Satin Nickel
Architectural Grade
Corrosion-Resistant Finish for Demanding Environments

The satin nickel surface undergoes multi-stage passivation treatment,whether installed in coastal resort lobbies with high salinity air, humid indoor swimming pool areas, or climate-controlled museum galleries, the gripper maintains both its mechanical integrity and visual appeal throughout decades of service.

  • UV-stable finish — no discoloration under exhibition lighting
  • Withstands -20°C to +80°C operating temperature range
  • Compact 32*20*14mm body blends discreetly into ceiling architecture
📐 Primary Applications
Heavy Chandelier Suspension Theater Lighting Grids Public-Atrium Overhead Rigging HVAC Duct Suspension Acoustic Baffle Arrays Solar Shade Tension Systems
📦 Packaging & QC
  • Individual anti-tarnish polybag packaging
  • 100% dimensional QC + random 5% load-to-failure batch testing
  • ISO 9001:2015 certified, RoHS & REACH compliant
MOQ
100 PCS
Per Model
